1 Year General Warranty.
DOUBLE RELAY ELSD
In case of electricity surges, both live and neutral current flows will be cut off, ensuring your safety at multiple levels.
SAFETY THERMAL CUT-OFF
Automatic and Overload Temperature Control System automatically breaks off power supply if the is abnormal rise in shower temperature.
SPLASH PROOF
The casing is designed to provide protection against water seeping into the heater's internal mechanism.
NYLON FIBRE INTERNAL
The internal of the heater is build with this strong and durable non-conductive material for futher insulation against electric shock.
TECHNICAL SPECIFICATIONS
- Model: V10-E
- Pump Type: N/A
- Pump Rating: N/A
- Noise Level: N/A
- Heater Power Rating: 3.60kW, 240V ̴ 50 Hz
- Water Connection: vowel 15.0 mm (1/2" BSP)
- Operating Condition: Open Outlet
- Protection Against Electric Shock: Class 1
- Water Temperature Control: Electronics
- Degree of Protection: IP25
- Minimum Flow Rate: 3 Liters / Minute
- Minimum Pressure: 20 kPa (0.2 bar / 2.9 psi)
- Maximum Inlet Pressure: 0.38 MPa (3.8 bar / 55 psi)
- Heater Dimension: 220mm (W) x 380mm (L) x 96mm (H)
- Nett Weight: 2.8 kg
