1 YEARS GENERAL WARRANTY.

MAXIMUM BREEZE, MINIMAL NOISE

The Regulator Ceilling Fan provides you with maximum airflow with an amazing level of quientness.

• 5-speed Electronic Regulator
• Enhanced Safety Features

Reliable - Multi-Level Safety Protection

Thermal Safety Fuse
Against fire hazard, prevents electric shooks and protects motor from current surge.

Current Fuse
Prevent current leakage or abnormal current.

Safety wire
Safety wire secures the fan motor to the ceilling hook to prevent detachment of the fan motor from rod.

Cut-off Safety Switch
Cut off power supply while detecting dagerous wear and tear of the shaft or bolt.

Blade Safety Plate
A fall prevention plate is installed on the blade to prevent fan blade to detach and dropping from the ceilling in case it damages.

SPECITICATION

General Information

• Fan Speed (RPM)
  • (Low): 81 - 118
  • (High): 216 - 264
• Power Consumption (W)
  • (Low): 15 - 20
  • (High): 67 - 82
• Air Velocity: 165 m/min
• Air Delivery: 230 m/min
• Motor HP: 0.11
• Motor Type: 14 Pole Condenser Motor
• Noise Level (dB): 54
• Nett Weight (kg): 7.3
• Length from pully to PCB cover (mm): 439
• Length from pully to blade (mm): 348

NOTE :

Design and specifications are subject to chance without notice
