3 Years General Warranty. 10 Years Compressor Warranty.

UV Cool Smart + Series

HS-19VRB03

Highlights

• AI ECO
• UVC Sterilization

Specs

BTU/h: 19000 (4200-19000)

Specification

Capacity

• Capacity (W): 5567
• Capacity (BTU): 19000 (4200-19000)
• Power input (W): 1600
• CSPF: 5.3
• Star Rating: 5
• Running current (A): 7.3
• Power supply (Ph/V/Hz): 1/220-240/50
• Air circulation (m³/h): 800
• Moisture removal (10¯³m³/h): 1.8
• Refrigerant: R32
• Refrigerant pipe (mm): 6.35
• Type: 12.70

INDOOR

• Net dimension (mm): 875/212/304
• Package dimension (mm): 945/296/390
• Net weight (kg): 10.5
• Gross weight (kg): 12.5
• Noise [dB(A)] (Hi/Mid/Lo/So): 46/42/38/32

OUTDOOR

• Outdoor Net dimension (mm): 800/280/553
• Outdoor Package dimension (mm): 902/375/614
• Outdoor Net weight (kg): 25.0
• Outdoor Gross weight (kg): 27.8
• Noise [dB(A)]: 54
• Max Pipe Length(m): 25
• Max Pipe Height(m): 15
• Chargless Piping Length(m): 5
• Amount of additional Refrigerant (g/m): 20
• Amount of Gas(g): 680
• Power Supply: Indoor
• Metering Device: Capillary Tube
