3 Years General Warranty. 10 Years Compressor Warranty.
UV Cool Comfort Series
HS-10VQJ09
Highlights
- AI ECO
- UV Sterilisation
Specs
BTU/h: 9500(3200-9800)
SPECIFICATIONS
Capacity
- Capacity (W): 2784
- Capacity (BTU): 9500(3200-9800)
- Power input (W): 840
- CSPF: 5.2
- Star Rating: 4
- Running current (A): 3.7
- Power supply (Ph/V/Hz): 1/220-240/50
- Air circulation (m³/h): 600
- Moisture removal (10¯³m³/h): 1.2
- Refrigerant: R32
- Refrigerant pipe (mm): 6.35
- Type: 9.52
INDOOR
- Net dimension (mm): 65/270/198
- Package dimension (mm): 16/321/248
- Net weight (kg): .2
- Gross weight (kg):
- Noise [dB(A)] (Hi/Mid/Lo/So): 9/35/29/24
OUTDOOR
- Outdoor Net dimension (mm): 660/245/463
- Outdoor Package dimension (mm): 767/314/516
- Outdoor Net weight (kg): 17.5
- Outdoor Gross weight (kg): 20
- Noise [dB(A)]: 50
- Max Pipe Length(m): 15
- Max Pipe Height(m): 10
- Chargless Piping Length(m): 5
- Amount of additional Refrigerant (g/m): 20
- Amount of Gas(g): 370
- Power Supply: Indoor
- Metering Device: capillary tube
