3 Years General Warranty. 10 Years Compressor Warranty.

Inverter Series

HS-19VSC03(S)

Highlights

• Wi-Fi Control
• UVC Pro
• AI ECO

Specs

• Silver/5400/18430/1260

SPECIFICATIONS

Compressor

• Type: Inverter

Model

• Indoor/Outdoor: HS-19VSC03(S)

CAPACITY

• Capacity (W): 5400
• Capacity BTU/h: 18430
• Power input (W): 1310
• CSPF: 6.4
• Star Rating: 5
• Running current (A): 6
• Power supply (Ph/V/Hz): 1/220-240/50
• Air circulation (m³/h): 1260
• Moisture removal (10¯³m³/h): 2
• Refrigerant: R32
• Refrigerant pipe (mm) Liquid side diameter: 6.35
• Refrigerant pipe (mm) Gas side diameter: 12.7

INDOOR

• INDOOR Net dimension (mm): 1105×240×345
• INDOOR Package dimension (mm): 1185×428×331
• INDOOR Net weight (kg): 15
• INDOOR Gross weight (kg): 18.5
• INDOOR Noise [dB(A)] (Hi/Mid/Lo/So): 44/42/39/32

OUTDOOR

• Net dimension (mm): 800×280×553
• Package dimension (mm): 902×375×614
• Net weight (kg): 29.4
• Gross weight (kg): 32.2
• Noise [dB(A)]: 54
• Max Pipe Length(m): 25
• Max Pipe Height(m): 15
• Chargless Piping Length(m): 5
• Amount of additional Refrigerant (g/m): 20
• Amount of Gas(g): 900
• Power Supply: Indoor
• Metering Device: Expansion Valve
