3 Years General Warranty. 10 Years Compressor Warranty.

Inverter Series

HS-10VSC03(S)

Highlights

• Wi-Fi Control
• UVC Pro
• AI Eco

Specs

• Silver/2840/9690/680

SPECIFICATIONS

Compressor

• Type: Inverter

Model

• Indoor/Outdoor: HS-10VSC03 (S)

CAPACITY

• Capacity (W): 2840
• Capacity BTU/h: 9690
• Power input (W): 800
• CSPF: 5.4
• Star Rating: 5
• Running current (A): 3.6
• Power supply (Ph/V/Hz): 1/220-240/50
• Air circulation (m³/h): 680
• Moisture removal (10¯³m³/h): 1.4
• Refrigerant: R32
• Refrigerant pipe (mm) Liquid side diameter: 6.35
• Refrigerant pipe (mm) Gas side diameter: 9.52

INDOOR

• INDOOR Net dimension (mm): 805/200/292
• INDOOR Package dimension (mm): 874/270/363
• INDOOR Net weight (kg): 8.7
• INDOOR Gross weight (kg): 10.5
• INDOOR Noise [dB(A)] (Hi/Mid/Lo/So): 40/37/32/27

OUTDOOR

• Net dimension (mm): 660×245×463
• Package dimension (mm): 767×314×516
• Net weight (kg): 18.5
• Gross weight (kg): 20.5
• Noise [dB(A)]: 50
• Max Pipe Length(m): 15
• Max Pipe Height(m): 10
• Chargless Piping Length(m): 5
• Amount of additional Refrigerant (g/m): 20
• Amount of Gas(g): 390
• Power Supply: Indoor
• Metering Device: capillary tube
