3 Years General Warranty.

QD-Mini LED Series

H85M80FUX

Highlights

• QD-Mini LED
• Sound by KEF
• Google TV

Specs

60fps/85"/6.5ms/3840*2160

Features

Specifications

General

• Screen Size: 85”
• Smart TV: Google TV
• Wall Mounts Standard(VESA): 600x300mm
• Bluetooth: 5.1
• WIFI: wifi5
• Active Screen Area（inch): 84.6"
• Type: QD-Mini LED

Panel

• Aspect Ratio: 0.6729166667
• Resolution: 3840*2160
• Brightness(cd/m2) in Energy Saving Mode: ≥65%
• Colour Gamut: QLED
• Colour Gamut Data（DCI-P3\NTSC): Typical-94%（DCI-P3）/Mini 93%
• Contrast Ratio: 5600:1
• Dynamic Contrast Ratio: 1000000：1
• Array Backlight: MINILED
• Response Time: 6.5ms(TYPICAL)
• Color Depth: 1.07B
• Refresh Rate: 60Hz
• Viewable Angle(H/V): 178
• Super Woofer: YES

Audio

• Surrounding Sound（Simulate）: YES
• Mute: YES
• NICAM: YES
• Stereo Speaker: YES
• Auto Volume Leveling: YES
• Sound balance: YES
• Sound EQ: YES
• Audio-Only (Picture off): YES
• Dolby Digital Decoding: YES
• dbx-tv: YES
• Dobly Atoms: YES
• HDMI Input: 4(HDMI 2.1 Compliance ALLM  eARC)

Input/Output

• Tuner Input: 1
• Composite Input: 1*RCA
• Shared Audio Input: 1
• Headphone Jack: 1
• USB ports: 2(USB 2.0）
• SPDIF: 1
• Ethernet LAN: 1
• Wireless Wifi Access: YES
• CPU: ARM Advanced Multi-Core Cortex CA55

Applications and Hardware

• Graphics: ARM Advanced Multi-Core Mali G52MC1
• RAM: 2 G Byte DDR3
• ROM: 32G Byte  Flash
• System: Google 5.0
• Applications-Netflix: Yes
• Applications-Youtube: Yes
• Applications-Google Play Store: Yes
• Applications-Google Assistant: Yes
• Live TV: Yes
• Far field vocie control: FFGA(Far field with Google Assistant）

Software

• Shopping Mode: YES
• HDR10: YES
• Dolby Vision: YES
• HLG: YES
• Multi-Audio Modes: User/Standard/Sports/Movie/Music/News
• Wide Mode: Automatic/Super zoom/4:3/Movie expand 14:9/Movie expand 16:9/Full/Unscaled
• Energy Saving: YES
• Color temperature: User/Standard/Warm/Cool
• Default Color temperature: Standard
• Digital Noise Reduction: YES
• MEMC: YES（60Hz）
• 3D comb-filter: YES
• 3D de-interlace: YES
• Channel Edit: YES
• Favourite List: YES
• USB File system: FAT32 NTFS
• Parental controls: YES
• Chromecast: YES
• HDMI ARC: YES(HDMI1 ARC)
• HDMI CEC: YES
• Auto-Timer on/off: YES
• PVR: YES
• Timeshift: YES

Accessory

• RC model: HTR-U35G
• Power Cord: 1.8m
• No. of Built-in Speakers: 3

Physical Characters

• Rated Power Consumption: 420W
• Standby Power Consumption: ≤0.5W
• Voltage Range: 100-240V 50/60Hz
• Net Weight (W/OStand): 32.3kg
• Net Weight (With Stand): 33.6kg
• Gross Weight: 46.6kg
• Net Dimension(Without Stand): 1890x1088x98mm
• Net Dimension(With Stand): 1890x1130x367mm
• Packaging Dimension: 2055x210x1200mm
